Standard

Video: PAL; NTSC Audio: G.711A

Video Compression

H.264(High Profi­le)

Video Display

1/4/8/16/24/32 split display

Video Input

5M:8-ch3M:16-ch 1080P:24-ch 960P:32-ch

Video Output

RJ45/1-ch VGA，1ch HDMI

Audio I/O

1-ch RCA/1-ch RCA

Backup

Network backup, USB mobile hard disk

Local Playback

5M:2-ch3M:4-ch 1080P:4-ch 960P:8-ch real-time playback

Playback Resolution

5M/3M/1080P/960P

Storage

8 SATAs (Totally 24TB) , 1 ESATA interface

16-ch input / 4-ch output

Alarm interface

Network Interface

1 RJ4510M/100M/ 1000M adaptive ethernet Interface

USB Interface

2 USB ports

Serial Interface

1 RS-485 half-duplex interface

Working Conditions

0℃-＋55℃ 10%－90% RH

Power Supply

220V

Dimension(color box)

570mm*212mm*575mm

Net/Gross Weight

5.84kg/6kg
