Standard

Video: PAL; NTSC Audio: G.711A

Video Compression

H.264(High Profi­le)

Video Display

1/4/9 split display

Video Input

1080P:8-ch; 720P:8-ch

Video Output

1-ch BNC/1-ch VGA/1-ch HDMI

Audio Output

1-ch RCA

Backup

Network backup, USB mobile hard disk

Local Playback

1080P: 1/2-ch; 720P:8-ch

Playback Resolution

1080P/720P

Storage

2 SATA (Totally Max 6TB)

Network Interface

1 RJ4510M/100M adaptive ethernet interface

USB Interface

2 USB ports

Serial Interface

1 RS-485 half-duplex interface

Working Conditions

0℃-＋55℃ 10%－90% RH

Power Supply

12V/4A

Dimensions(color box)

390mm*118mm*345mm

Net/Gross Weight

1.62kg/3kg
