Technical Specifications

Model

ZKMD532

Image Sensor

1/4’’ CMOS

Image Resolution

1280*720

Minimum Illumination

1 Lux（IR off），0 Lux（IR on）

Day/Night Mode

Automatically IR-cut filter

Lens Type

3.6mm fixed lens

IR Distance

1pcs array IR light , 60°projection angle,5-8 meters valid

System

LINUX

Video Compression

H.264 main profile level 3

Video Resolution

Main stream：1280x720/Secondary stream：640x352/Third stream：320x176

Image Streaming

32Kbits/s～6144Kbits/s settable

Video Frame Rate

PAL：1-25 frame NTSC:1-30 frame

Image Settings

Brightness 、Contrast 、Saturation、Shutter

Control Port

reset

Motion Detection

4 independent detection areas settable

Network Interface

100M

Power Supply

12V / 1A

Power Consumption

<5W

Working Temperature

-10℃~ 55℃

Net Weight

0.5KG
