- Real-time H.265/H.264 Image Compression
- 2.0 Megapixels, 30X optional Zoom
- Support Android and IOS system
- Real-time H.265/H.264 Image Compression
- 2.0 Megapixels, 30X optional Zoom
- Support Android and IOS system
- IP66-rated protection against dust and rain
- Support Onvif 2.0+, Compatible with mainstream NVR/HVR/NVD
- Easy connection and installation
Technical Specifications |
|
|
Model |
PT-SDC20K9 |
|
Image Sensor |
1/2.9" CMOS Sensor |
|
Image Resolution |
2.0 Megapixels (1920*1080) |
|
Minimum‑Illumination |
Color：0.01Lux@F1.2, B&W：0.001Lux@F1.2 |
|
Day & Night |
IR-Cut |
|
IR Distance |
120m |
|
Focus Mode/ Gain Compensation |
AUTO/Manual |
|
White Balance |
AUTO, Manual, ATW, OutdoorIndoor |
|
S/N Ratio |
>48dB |
|
Noise Reduction |
2D/3D |
|
Max Aperture |
F3.5~F1.6 |
|
Lens |
4.3-129mm, 30X optional zoom |
|
Pan |
360° endless |
|
Tilt |
-2°～90° |
|
Zoom |
30X optical zoom |
|
Preset Position |
255 preset positions |
|
PTZ features |
Outage memory function |
|
Dual-Stream |
Support |
|
Video Compression |
H.265/H.264 |
|
WDR |
D-WDR |
|
Electronic Shutter |
1/25 - 1/10000sec |
|
Memory function |
Memory function |
|
Support Protocol |
TCP/IP, DHCP, DNS, RTP, RTSP, HTTP,PPPOE,FTP |
|
Patterns |
4 patterns |
|
Patrol |
8 patrols |
|
Casing |
Camera:Metal(Aluminum Alloy); Color: white |
|
Power Supply |
DC12V |
|
Power Consumption |
48W MAX |
|
Working Conditions |
-40℃～+65℃,＜90%RH non-condensing |
|
Protection Rating |
IP66 |
|
Net Weight |
4.7kg |
