Product Model

GT-ADR401M

Video Compression

H.264 (High Profile)

Video Input

Analog: 4*AHD-M ;

Mixed: 2* AHD-M (analog)+2*720P (network);

Network: 8*720P; 8*1080P;

Audio Compression

G.711A

Audio Input

4-ch RCA

Video Output

1-ch VGA, 1-ch HDMI

Audio Output

1-ch RCA

Backup

Network backup, USB mobile hard disk

Playback

4 channels (1-ch real time)

Hard Disk Interface

1 SATA (Max to 3TB)

Space Occupied

720P 20G / day;960H 12~20G / day*channel; Audio: 691.2M / day*channel

Input

4-ch BNC

Network Interface

RJ45 10M/100M adaptive ethernet interface

USB Interface

2 USB 2.0 ports

Serial Interface

1 RS-485 support multi kinds of PTZ protocol

Power

12V/2A

Dimensions

345mm*95mm*275mm

Net/Gross Weight

1.0kg/1.8kg
