- Support P2P function and Cloud Service
- Support Android, IOS system
- Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP networking protocol
- Support Onvif 2.0+, Compatible with mainstream NVR
- Support Night vision, IR distance is 15 meters
|
Model |
GT-BB510 |
GT-BB513 |
GT-BB520 |
|
Sensor |
Omnivision OV9712 |
Aptina AR0130 |
SONY IMX122 |
|
Light-sensing Area |
1/4-inch |
1/3-inch |
1/3-inch |
|
Pixels |
1.0MP |
1.3MP |
2.0MP |
|
Definition |
1280(H)x720(V) |
1280(H)x960(V) |
1920(H)x1080(V) |
|
Main Stream |
1280x720 / 704x576 |
1280x960 / 1280x720 |
1920x1080 / 1280x720 |
|
Secondary Stream |
PAL:704x576; 352x288 / NTSC:704x480; 352x240 |
||
|
Video Frame |
PAL:25 frame; NTSC:30 frame |
||
|
Frame Rate |
Main stream:1-4Mbps |
Main stream:1-5Mbps |
Main stream:1-8Mbps |
|
Second stream:0.5-2Mbps |
Second stream:0.5-2Mbps |
Second stream:0.5-2Mbps |
|
|
Min. Illumination |
IR on: 0 Lux |
||
|
Lens |
3.6mm fixed lens (6mm and 8mm fixed lens optional) |
||
|
Signal Noise Ratio |
40dB |
45dB |
52dB |
|
White Balance |
Auto |
||
|
Shutter |
Auto |
||
|
Infrared Resection |
IR-CUT |
||
|
IR Distance |
15m |
||
|
Power Supply |
DC 12V /1.5A |
||
|
Operating Temperature |
-10℃～+50℃ |
||
|
Mobile View |
IPhone，Android |
||
|
ONVIF |
Onvif 2.0+ |
||
|
Network Delay |
Less than 300ms in LAN |
||
|
Web Interface
|
Embedded web server, supports real-time video and audio preview, configuration, control via IE browser |
||
|
Alarm Trigger |
Alarm via email server(send snapshot or not);upload video to FTP server; |
||
|
Video Storage |
Support saving via FTP, client end software |
||
|
Remote Control |
Via web server/client end software |
||
|
Protection Rating |
IP65 |
||
|
Net/Gross Weight |
0.54kg/0.74kg |
||
|
Dimension (color box) |
230mm*127mm*127mm |
||
