Standard

Video: PAL; NTSC Audio: G.711A

Video Compression

H.264(High Pro­file)

Video Display

1/4/9/16 split display

Video Input

3M:4-ch;1080P:8-ch; 960P:16-ch

Video Output

RJ45/VGA/HDMI

Audio I/O

1-ch RCA/1-ch RCA

Backup

Network backup, USB mobile hard disk

Local Playback

3M:1-ch; 1080P: 2-ch; 960P:4-ch 720P:real time

Playback Resolution

3M/1080P/960P

Storage

2 SATAs (Totally Max 6TB)

Network Interface

1 RJ4510M/100M adaptive ethernet interface

USB Interface

2 USB ports

Serial Interface

1 RS-485 half-duplex interface

Working Conditions

0℃-＋55℃ 10%－90% RH

Power Supply

12V/4A

Dimension(color box)

390mm*118mm*345mm

Net/Gross Weight

1.62kg/3kg
