Model

GT-NR401

GT-NR801

GT-NR1601

Standard

Video: PAL; NTSC Audio: G.711A

Video Compression

H.264(High Profile)

Video Display

1/4 split display

1/4/9 split display

1/4/9/16 split display

Video Input

1080P:8-ch; D1:8-ch

1080P: 8-ch; 720P: 8-ch; D1:16-ch

3M:4-ch 1080P:8-ch 960P:16-ch

Video Output

1-ch VGA, 1-ch HDMI

Audio I/O

N/A

N/A

1-ch RCA/1-ch RCA

Backup

Network backup, USB mobile hard disk

Local Playback

1080P:1-ch: D1: 4-ch

1080P: 1/2-ch: 720P:4-ch

3M:1-ch; 1080P: 2-ch; 960P:2-ch; 720P:4-ch

Playback Resolution

1080P/D1

1080P/720P/D1

3M/1080P/960P

Storage

1 SATA (Max 3TB)

Network Interface

1 RJ45 10M/100M adaptive ethernet interface

USB Interface

2 USB ports

Serial Interface

1 RS-485 half-duplex interface

Working Conditions

0℃-＋55℃ 10%－90% RH

Power Supply

12V/2A

Dimensions(color box)

345mm* 95mm*275mm

Net/Gross Weight

975g/1.8kg
