Product Model

HVR0402

HVR0804

Main Processor

industrial embedded micro-controller

Operation System

Embedded Linux

IP Camera Input

4 channel

8 channel

Audio

1 channel input (line in)， 1channel output

Interface

1 VGA 1, CVBS

1 HDMI,1 VGA, 1 CVBS

Resolution

1280×1024, 1024×768,704×576

1920×1080,1280×1024,704×576

Display split

1/4

1/4/8

OSD

Camera title, Time, Motion detection, Recording

Compression

H.264

Resolution

720P(1280×720) / D1(704×576/704×480) / 640x352

Record Rate

120fps @ 720p

240fps @ 720p

Bit Rate

48~6144kbps

Record Mode

Manual, Schedule,Stop

Record Interval

1~120 min (default: 60 min), Pre-record: 1~10 sec,

Trigger Events

Recording, PTZ, Tour, Email, Buzzer & Screen tips

Video Detection

Motion Detection

Alarm Input

2 channel

Alarm Output

2 channel

Sync Playback

1 channel

Search Mode

Time/Date, MD & Exact search

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow play, Next ­le etc

Backup Mode

USB Device / Network

Ethernet

1 RJ-45 port (10/100Mbps)

Network Function

HTTP, TCP/IP, UPNP, UDP, NTP, DHCP, DNS, IP Filter, PPPOE,DDNS, FTP, IP Search,SMTP,ONVIF

Smart Phone

iPhone, Android

Internal HDD

2 SATA ports, up to 4TB

4 SATA ports, up to 8TB

USB

2 ports (USB2.0)

Power Supply

DC12V±10% ( External )

Power Consumption

<15W

<20W

Work Temperature

0℃~ +55℃

Working Humidity

10%～90%

Atmospheric Pressure (atm)

86kpa～106kpa

Dimension

370(L)x263(W)x70(H)mm

Weight

3KG(exclude hard disk)
